不銹鋼球閥廠家為您詳細分析：銅球閥和不銹鋼球閥的區別在哪里？
The stainless steel ball valve manufacturer makes a detailed analysis for you: What is the difference between copper ball valve and stainless steel ball valve?
銅球閥和不銹鋼球閥有一下五點區別：
There are five differences between copper ball valve and stainless steel ball valve:
1、材質不同：它們采用的材質完全不同，銅球閥采用的材料主要以銅組成。，不銹鋼球閥采用的是不銹鋼。
1. Different materials: they are made of completely different materials. The copper ball valve is mainly made of copper., Stainless steel ball valve is made of stainless steel.
2、耐腐蝕性不同：銅球閥耐腐蝕性比不銹鋼球閥好，開關操作順暢省力，耐久不漏。不銹鋼不會產生腐蝕、點蝕、銹蝕或磨損以及耐高溫。一般不銹鋼的貴點了。
2. Different corrosion resistance: the corrosion resistance of copper ball valve is better than that of stainless steel ball valve. The switch operation is smooth, labor-saving and durable. Stainless steel will not produce corrosion, pitting, rust or wear and is resistant to high temperatures. Generally, stainless steel is more expensive.
3、溫度不同：按相同壓力環境下，如果介質溫度不超過80度，則用不銹鋼球閥就可以了，如果溫度超過80度則必需要用銅球閥。
3. Different temperatures: under the same pressure environment, if the medium temperature does not exceed 80 degrees, stainless steel ball valves can be used; if the temperature exceeds 80 degrees, copper ball valves must be used.
4、價格不同：銅球閥造價材料比較貴，不銹鋼球閥造價材料比銅球閥便宜。
4. Price difference: copper ball valve is more expensive, while stainless steel ball valve is cheaper than copper ball valve.
5、適用物質不同：不銹鋼球閥可用于控制空氣、水、蒸汽、各種腐蝕性介質、泥漿、油品、液態金和放射性介質等各種類型流體的流動；銅球閥適用于水、溶劑、酸和天然氣等一般工作介質，而且還適用于工作條件惡劣的介質，如氧氣、過氧化氫、甲烷和乙烯等。
5. Applicable substances are different: stainless steel ball valves can be used to control the flow of air, water, steam, various corrosive media, mud, oil, liquid gold, radioactive media and other types of fluids; Copper ball valves are suitable for general working media such as water, solvent, acid and natural gas, and also for media with poor working conditions, such as oxygen, hydrogen peroxide, methane and ethylene.
不銹鋼球閥
Stainless steel ball valve
不銹鋼球閥只需要用旋轉90度的操作和很小的轉動力矩就能關閉嚴密。完全平等的閥體內腔為介質提供了阻力很小、直通的流道。球閥的主要特點是本身結構緊湊，易于操作和維修，不銹鋼球閥可用于控制空氣、水、蒸汽、各種腐蝕性介質、泥漿、油品、液態金屬和放射性介質等各種類型流體的流動。球閥閥體可以是整體的，也可以是組合式的。本類閥門在管道中一般應當水平安裝。
The stainless steel ball valve can be closed tightly with only 90 degree rotation operation and small rotation torque. The completely equal inner cavity of the valve body provides a straight flow passage with little resistance for the medium. The main characteristics of the ball valve are its compact structure, easy operation and maintenance. The stainless steel ball valve can be used to control the flow of various types of fluids such as air, water, steam, various corrosive media, mud, oil, liquid metal and radioactive media. The valve body of the ball valve can be integral or combined. This type of valve shall be installed horizontally in the pipeline.
銅球閥
Copper ball valve
銅球閥是本身結構緊湊，密封可靠，結構簡單，維修方便，密封面與球面常在閉合狀態，不易被介質沖蝕，易于操作和維修，適用于水、溶劑、酸和天然氣等一般工作介質，而且還適用于工作條件惡劣的介質，如氧氣、過氧化氫、甲烷和乙烯等，在各行業得到廣泛的應用。球閥閥體可以是整體的，也可以是組合式的。
The copper ball valve is compact in structure, reliable in sealing, simple in structure, and easy to maintain. The sealing surface and spherical surface are often closed, not easily eroded by the medium, and easy to operate and maintain. It is suitable for general working media such as water, solvent, acid, natural gas, and also for media with poor working conditions, such as oxygen, hydrogen peroxide, methane, ethylene, etc. It is widely used in various industries. The valve body of the ball valve can be integral or combined.
分類：
Classification:
不銹鋼球閥分類
Classification of stainless steel ball valves
1.不銹鋼氣動球閥，不銹鋼電動球閥，不銹鋼手動球閥。不銹鋼球閥材質分為304,316,321不銹鋼球閥。
1. Stainless steel pneumatic ball valve, stainless steel electric ball valve, stainless steel manual ball valve. Stainless steel ball valves are made of 304316321 stainless steel ball valves.
2.不銹鋼球閥靠旋轉閥芯來使閥門暢通或閉塞。球閥開關輕便，體積小，可以做成很大口徑，密封可靠，結構簡單，維修方便，密封面與球面常在閉合狀態，不易被介質沖蝕，在各行業得到廣泛的應用。只有它的關閉件是個球體，球體繞閥體線作旋轉來達到開啟、關閉的一種閥門。
2. The stainless steel ball valve is unblocked or blocked by rotating the valve element. The ball valve is light to open and close, small in size, can be made into a large diameter, reliable in sealing, simple in structure, and convenient in maintenance. The sealing surface and spherical surface are often closed, and are not easy to be eroded by the medium. It is widely used in various industries. Only its closing part is a sphere, which rotates around the center line of the valve body to open and close the valve.
銅球閥分類
Classification of copper ball valves
1.按銅球閥結構型式分類：浮動球式、固定球式。主要產品例如：法蘭浮動球閥、固定球兩片式球閥、固定球軟密封球閥、襯氟球閥、固定球不銹鋼高溫球閥等。2.按銅球閥流通型式分類：直通式、三通式、四通式、五通式。主要產品例如：直通一片式球閥、三通法蘭球閥等。3.按銅球閥裝配形式分類：一體式、二體式、三體式、上裝式。主要產品例如：兩體襯氟球閥、三體不銹鋼球閥、上裝式球閥等。4.按銅球閥流道直徑分類：全通徑式、縮徑式。主要產品例如：全通徑法蘭球閥、縮徑式球閥等。銅球閥和不銹鋼球閥的優點:
1. Classification according to the structural type of copper ball valve: floating ball type and fixed ball type. Main products include: flanged floating ball valve, fixed ball two-piece ball valve, fixed ball soft seal ball valve, fluorine lined ball valve, fixed ball stainless steel high-temperature ball valve, etc. 2. Classification according to the flow type of copper ball valve: straight, three-way, four-way and five way. The main products are: straight one piece ball valve, three-way flange ball valve, etc. 3. Classification according to the assembly form of copper ball valve: integrated type, two body type, three body type and top mounted type. The main products are: two body fluorine lined ball valve, three body stainless steel ball valve, top mounted ball valve, etc. 4. Classification according to the flow passage diameter of copper ball valve: full bore type and reduced bore type. The main products are: full bore flanged ball valves, reduced bore ball valves, etc. Advantages of copper ball valve and stainless steel ball valve:

1.流體阻力小，其阻力系數與同長度的管段相等。
1. The fluid resistance is small, and its resistance coefficient is equal to that of pipe sections of the same length.
2.結構簡單、體積小、重量輕。
2. Simple structure, small volume and light weight.
3.緊密可靠，球閥的密封面材料廣泛使用塑料、密封性好，在真空系統中也已廣泛使用。
3. It is tight and reliable. The sealing surface material of the ball valve is widely made of plastic with good sealing performance. It has also been widely used in the vacuum system.
4.操作方便，開閉迅速，從全開到全關只要旋轉90°，便于遠距離的控制。
4. It is easy to operate and can be opened and closed quickly. Only 90 ° rotation is required from full opening to full closing, which is convenient for remote control.
5.維修方便，球閥結構簡單，密封圈一般都是活動的，拆卸更換都比較方便。
5. It is easy to maintain, the ball valve is simple in structure, the sealing ring is generally movable, and it is convenient to disassemble and replace.
6.在全開或全閉時，球體和閥座的密封面與介質隔離，介質通過時，不會引起閥門密封面的侵蝕。
6. When the valve is fully opened or closed, the sealing surfaces of the ball and valve seat are isolated from the medium. When the medium passes through, it will not cause erosion of the valve sealing surface.
7.適用范圍廣，通徑從小到幾毫米，大到幾米，從高真空至高壓力都可應用。
7. It has a wide range of applications, ranging from a few millimeters to several meters in diameter, from high vacuum to high pressure.
銅球閥和不銹鋼球閥的使用方法:
Usage of copper ball valve and stainless steel ball valve:
1、操作前須確認管路和閥已被沖洗過。
1. Before operation, confirm that the pipeline and valve have been flushed.
2、閥的操作按執行機構輸入信號大小帶動閥桿旋轉完成：正向旋轉1/4圈(900)時，閥關斷。反向旋轉1/4圈(900)時，閥開啟。
2. The operation of the valve will drive the valve rod to rotate according to the input signal of the actuator: when it rotates 1/4 circle (900) in the positive direction, the valve will be closed. The valve opens when it is rotated 1/4 turn (900) in the opposite direction.
3、當執行機構方向指示箭頭與管線平行時，閥門為開啟狀態;指示箭頭與管線垂直時，閥門為關閉狀態。
3. When the direction indicating arrow of the actuator is parallel to the pipeline, the valve is open; When the indicating arrow is perpendicular to the pipeline, the valve is closed.
銅球閥和不銹鋼球閥安裝和維修
Installation and maintenance of copper ball valve and stainless steel ball valve
球閥安裝：
Ball valve installation:
1、必須確認管路和閥操作前已經清洗過了。
1. It must be confirmed that the pipelines and valves have been cleaned before operation.
2、閥門的執行機構操作根據輸入信號的大小帶動閥桿旋轉完成：正向旋轉1/4圈(900)時，閥關斷。反向旋轉1/4圈(900)時，閥開啟。
2. The actuator operation of the valve drives the valve rod to rotate according to the size of the input signal: when it rotates 1/4 circle (900) in the positive direction, the valve is closed. The valve opens when it is rotated 1/4 turn (900) in the opposite direction.
3、當執行機構方向指示箭頭與管線平行時，閥門打開；箭頭與管線垂直時，閥門關閉。
3. When the direction indicating arrow of the actuator is parallel to the pipeline, the valve opens; When the arrow is perpendicular to the pipeline, the valve is closed.
球閥維修：
Ball valve maintenance:
有更長的使用壽命和免維護時間，將取決于幾個因素：正常的工作條件下，保持和諧的溫度/壓力比，以及合理的腐蝕數據。
A longer service life and maintenance free time will depend on several factors: maintaining a harmonious temperature/pressure ratio under normal working conditions, and reasonable corrosion data.
注意：球閥在關閉狀態下，閥體內的流體壓力依然存在
Note: When the ball valve is closed, the fluid pressure in the valve body still exists
維修前，拆下管線壓力并使閥門處于打開位置
Before maintenance, remove the line pressure and leave the valve in the open position
維修前，斷開電源或氣源
Disconnect the power or air supply before maintenance
維修前，將執行機構與支架脫離
Detach the actuator from the bracket before maintenance
